Ground Relay Electrical Reset (TYPE-9-22-ER4-2)

Make : Inderr
Type : EM (Electro Magnetic)
Used As : Ground
Rated Voltage : 74V
Rated Current : 10A
Braking Load : Inductive
No. of Auxiliary contracts : 4 Poles (L)
Rated Control Circuit Voltage : 300 mA
Material of the contracts : Hard silver overlay lamented to copper
Operating Voltages : All Equipment can be supplied in Control Voltages – 24V, 48V, 74V, 110DC
Operating Temperature : -20° to + 77° C
Standard Qualified : IEC-77, IEC-61373
Cycle Testing : Upto 1 Lakh

Category: Relays
