EP – Contactor (9-24PC-2-15)

Make : Inderr
Type : EP(Electro Pneumatic)
Rated Voltage : 1100V
Rated Current : 1390A
Braking Load : Inductive
No. of Auxiliary contracts : 3 No, 3 NC
Rated Control Circuit Voltage : 74 V DC
Material of the contracts : CU-TG-AG
Operating Voltages : All Equipment can be supplied in Control Voltages – 24V, 48V, 74V, 110DC
Operating Temperature : -20° to + 77° C
Standard Qualified : IEC-77, IEC-61373
Cycle Testing : Upto 1 Lakh

Category: Contactors

Share


EP – Contactor (9-24PC-2-15)

Get Support

0755-4272049

The Office Hours

Mon - Sat 8am to 6pm

Send Us Email

enquiry@inderrengineering.com

EP – Contactor (9-24PC-2-15)

Related products

EM – Contactor (9-22EC2)

EM – Contractor (9-50EC2)
